JBL

GTO629

Details
Item# GTO629_
Variations
  • Select Color
Product Actions
Add to cart options
kr 1.000,001000.0 per pair

Additional Information
Coaxial 6-1/2" (165mm) factory-sized replacement speakers
At a Glance:
  • 25 – 180 watts suggested amplifier power range
  • Patented Plus One woofer-cone technology
  • Fiberglass-reinforced plastic (FRP) frames
  • Three-ohm voice coils
  • Vented magnet assemblies
  • Frequency response to 21kHz
  • High sensitivity (93dB@2.83V/1m)
  • UniPivot and adjustable tweeter level
  • Edge-driven, soft-dome tweeter diaphragms
  • Speaker grilles and adapter mounting rings included
  • Industry leading product development and evaluation standards
What's in the box:
  • 1 pair of speakers
  • 1 pair of speaker grilles
  • User Manual
JBL® GTO 629 6-1/2-inch (165-millimeter) speakers handle a robust 180 watts peak power (60 watts RMS). This much power makes for an ideal match to systems powered with head-unit or factory-amplifier power levels. Even better, the speaker matches many of the GTO Series amplifier combinations. As a result, it can keep up with systems that feature one or more subwoofers. And its great power-handling specifications increase reliability over the lifetime of the speaker.
Product Features:
  • 25 – 180 watts suggested amplifier power range
    JBL engineers designed the GTO 629 coaxial speaker to produce strong, clear sound from a head-unit or amplifier capable of delivering up to 180 watts of power. This makes the GTO 629 an ideal match to systems powered with head-unit or factory-amplifier power levels. Even better, the speaker matches many of the GTO Series amplifier combinations. As a result, it can keep up with systems that feature one or more subwoofers. And its great power-handling specifications increase reliability over the lifetime of the speaker.
  • Patented Plus One woofer-cone technology
    The GTO 629’s Plus One carbon-injected cones provide more overall speaker-cone area than other cones in its class. With an effective increase in cone area, the speaker radiates more air. Its carbon-injected cone material results in a lighter and stiffer cone. The result is better low-frequency response and less effort to produce those important musical notes that people often associate with larger speaker sizes.
  • Carbon-Composite Non Magnetic Frame
    Looking for a longer lasting speaker? Look no futher than the GTO9 Series. Our Carbon-Compostie, non magentic frames maintain their integrity and precision even under thew most demanding conditions.
  • True 4 Ohm Technology
    Three-ohm voice coils in GTO 629 speakers allow compensation for any added resistance by thin factory-installed speaker wiring. They also provide more output than factory-installed speakers of the same class.
  • Vented magnet assemblies
    GTO 629 speakers feature vented magnet assemblies to cool the voice coil. Keeping the voice coil cool adds to increased reliability from greater power handling and helps eliminate power compression that can distort the speakers’ sound.
  • Frequency response to 21kHz
    A wide frequency response that extends beyond 20kHz helps to compensate for speaker-placement variations in your car and for human hearing deficiencies in the high-frequency spectrum above 15kHz. The result is that GTO 629 speakers deliver more of the full-range frequency response that you associate with great sound.
  • High sensitivity (93dB@2.83V/1m)
    High sensitivity allows a wide range of power to provide great sound without overdriving the audio system. With a sensitivity of 93 decibels at 2.83 volts/1 meter, the GTO 629 6-1/2'' (160-millimeter) speakers achieve excellent volume and musicality with as little as 5 watts RMS. That simply means better performance overall with even very moderate power driving the speaker. And better performance makes the speakers an ideal replacement for factory speakers as well as for any aftermarket speaker installation.
  • UniPivot and adjustable tweeter level
    UniPivot is an innovative feature on the GTO 629 that allows the tweeter to be aimed at the listening location for better stereo imaging and high-frequency response at the listener’s ear. You can also easily adjust the tweeter output from 0 to +3 decibels to compensate for low and off-axis mounting positions or road noise.
  • Edge-driven, soft-dome tweeter diaphragms
    The edge-driven, soft-dome tweeter design in the GTO 629 increases power handling while reducing high-frequency distortion. Edge-driven tweeters also have better dispersion characteristics and allow a lower crossover frequency, which improves imaging. The result is better vocals and clarity in your music. There’s no sense having it loud if it doesn’t sound clean, too.
  • Speaker grilles and adapter mounting rings included
    The GTO 629 speakers include an additional set of mounting adapter rings to allow the speakers to fit securely in a broad range of factory speaker openings that match this size. In addition, attractive black metal mesh grilles are also included to protect the speaker whenever it’s mounted in a location requiring a grille.
Plus One® Technology

Plus One carbon-injected cones provide more overall speaker-cone area than other cones in its class.

Highlights:
Manuals & Downloads:
General Specifications:
Type
Coaxial
Size
6-1/2"
Audio Specifications:
Sensitivity
(2.83V/1m) 93dB
Frequency Response
53Hz-21kHz
Power Handling (Peak)
180W
Nominal Impedance
3 ohms
Power Handling (RMS)
5W-125W
Dimensions:
Mounting Cutout Diameter (in)
5-1/16
Mounting Depth (in)
2
External Diameter (mm)
158
External Diameter (in)
6-1/4
Mounting Cutout Diameter (mm)
129
Mounting Depth (mm)
50
GTO629 is rated 5.0 out of 5 by 6.
Rated 5 out of 5 by from Quality Speakers! I bought these speakers for quality and my expectations were exceeded. The speakers gives out a rich clear sounds compare to my Lexus' factory speakers (Pioneer brand). However, the Bass is rather on the flat side but doable for the price.
Date published: 2016-03-09
Rated 5 out of 5 by from Awesome sound I put these in a 2005 Gto in the doors and rear quarter run by a Kenwood head unit. They sound great and very clear. Easy install with supplied universal adapter plate.
Date published: 2017-08-16
Rated 5 out of 5 by from Good sound I bought this product two weeks ago and I am so happy with this
Date published: 2017-04-10
Rated 5 out of 5 by from Geweldig geluid! Ik heb 2 weken geleden 2 setjes van deze speakers gekocht. Het geluid is helder en zeer diep! Het instaleren was makkenlijk. En niet te vergeten deze speakers zien er waanzinig uit!
Date published: 2018-03-06
Rated 5 out of 5 by from Good Bass Installed into 2007 Avalanche rear doors, best investment I have made. The sound quality over factory is night and day.
Date published: 2017-10-09
Rated 5 out of 5 by from Great item !! Very good quality , good build , great sound !!!!!!
Date published: 2018-07-16
  • y_2018, m_8, d_13, h_22
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.8
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_6
  • loc_en_NO, sid_gto629_, prod, sort_[SortEntry(order=RELEVANCE, direction=DESCENDING)]
  • clientName_harmanaudio

true 4 ohm? If i run 2 of these speakers in parallel on a 2 ohm rated amp will it shut the amp down? Would i have a 2 ohm load or 1.5 ohm?

Asked by: seany
We would like to work with you directly. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Dan E
Date published: 2018-07-15

Would this speakers fit on a Chevy Silverado 1500 extended cab?

Asked by: Isaifelix62
Unfortunately, it does not fit on a Chevy Silverado 1500 extended cab.
Answered by: Steven M
Date published: 2018-06-25

Would this speaker fit on a 2002 Chevy Silverado 1500 extended cab?

Asked by: Isaifelix62
We would like to work with you directly to help you with your issue. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Mario at Customer service
Date published: 2018-06-25

Will the speakers not work if I just put them in without an amp? And amp should I get?

Asked by: Isaifelix62
We would like to work with you directly to help you with your issue. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Mario at Customer service
Date published: 2018-06-25

I want to replace stock speakers on 2018 Silverado 1500, I want more bass than factory brand I'd like 6×9. Just because the spacing in rear seat is really tight and I came see big woofers fitting.. suggestions?! Heeelp hahaah

Asked by: Freddie Fred
We would like to work with you directly to help you with your questions. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Minete
Date published: 2018-06-15

Will these fit in my 2013 Volkswagen touareg (3.6L V6)? How many pair I should buy and what else parts I should buy to make them work? (any Amplifiers or subwoofers I should buy as well?)

Asked by: Flint
I can see that you've already submitted a case with us and is already being handled by one of our Customer Service Representatives. Please reply to their communication if you need anything additional.
Answered by: Rhae
Date published: 2018-06-06

Do I need a amp to run these?

Asked by: Js21
Yes, You will need an amp to run these speakers.
Answered by: Mario at Customer service
Date published: 2018-03-28

Will these fit in my 2002 Nissan Pathfinder?

Asked by: BrandonM
Yes, the JBL GTO629 should fit the front and rear doors of your 2002 Nissan Pathfinder.
Answered by: Steven M
Date published: 2017-12-02
